PAO / MIL-PRF-87252C / Royco 602
Unit of Measure
Technical Specs
Brands |
N/A Mydax, Inc. |
Temperature Range |
N/A 0 to +60 ºC |
Environment |
N/A Indoor |
BTU/hr |
N/A 16,000 |
kW |
N/A 6 kW at +20 ºC |
Tons |
N/A 1.33 |
Product Type |
N/A Unit - Air |
Stability |
N/A ±1.0 ºC |
Heating Capacity |
N/A 6,000 W |
Recirculating Flow/Pressure |
N/A 6 gpm at 80 psi Adjustable |
Stainless Steel Reservoir |
N/A 5 gallons |
Recirculating Fluid |
N/A Water |
Recirculating Supply |
N/A 3/4 in. Stainless Steel Female National Pipe Tapered (FNPT) |
Facilities Supply |
N/A 3/4 in. Stainless Steel Female National Pipe Tapered (FNPT) in |
Maximum Heat Rejection |
N/A 37,800 Btu/hr |
Condenser Requirements |
N/A 4,240 cfm Front-to-Rear |
Alternating Current (AC) Voltage |
N/A 200/220 V208/240 V |
Frequency at 208/240 Voltage |
N/A 60 Hz |
Frequency at 200/220 Voltage |
N/A 50 Hz |
Phase at 208/240 Voltage |
N/A 3 |
Phase at 200/220 Voltage |
N/A 3 |
Current at 208/240 Voltage |
N/A 40 A |
Current at 200/220 Voltage |
N/A 40 A |
Depth Including Filter |
N/A 36 in |
Approximate Dry Weight |
N/A 900 lb |
Warranty (Parts and Labor) |
N/A 12 months |
Patents |
N/A 4,742,689 4,934,155 4,959,972 |
Refrigeration |
N/A 5 Hp hermetically sealed scroll compressor, R-507 refrigerant |
Recirculation |
N/A 3 Hp magnetic-drive turbine pump powered by VFD, fluid flowmeter in recirculating return |
